Positioning Ceiling Mounted
Number of Domes 2
Field Diameter 150 mm
Brightness 160000 lux
Light Type LED
Features
Dual dome configuration for shadow-free illumination
48 + 48 high-efficiency medical grade LEDs
Adjustable light intensity & color temperature
High Color Rendering Index (CRI ≥95 Ra) for true tissue color
Sterilizable detachable handles
360° smooth arm rotation with perfect balance
Multi-function control panel & wireless remote
Low heat emission, surgeon comfort ensured
Fast and simple positioning with central control handle
Optional battery backup for uninterrupted operation
Technical Specifications
Number of LEDs: 48 + 48
Light Intensity: 160,000 × 2 Lux (Max)
Spot Diameter: 100 – 150 mm
Color Temperature: 3800 K – 5200 K (Adjustable)
Depth of Illumination: 10 – 15 cm
Color Rendering Index (CRI): ≥95 Ra
Diameter of Light Head: 500 mm + 500 mm
LED Life: > 50,000 hours
Intensity Control: 10 – 100% Digital
Power Supply: 220V / 50Hz AC
Power Consumption: 48 + 48 Watt
Special Function: 5 Memory Functions with Remote
Body Material: Aluminium
Structure: 360° Rotational Ceiling Structure
