Brand BMC
Mode CPAP, S, T, S/T
Humidifier Type Heated
Usage Hospital
Sound Level ≤30 dB
Power Supply 100–240V AC
Minimum order quantity: 100 Piece
Feature
Water Capacity
To maximum fill line 360 mL
Heated Humidifier
Humidifier Settings: Off, 1 to 5 (95°F to 154.4°F / 35°C to 68°C)
Humidifier Output: No less than 10 mg H₂O/L
Work Mode
CPAP, S, T, S/T
SD Card
The SD card can record patient data and fault information
AC Power Consumption
100 – 240 V AC, 50/60 Hz, 2.0 A
Sound Pressure Level
≤ 30 dB, when the device is working at the pressure of 10 hPa
Maximum Flow
Test Pressures (hPa):
4 | 9 | 15 | 20 | 25
Measured Pressure at the Patient Connection Port (hPa):
3 | 8 | 14 | 19 | 24
Average Flow at the Patient Connection Port (L/min):
90 | 120 | 150 | 150 | 150
Automatic Leak Compensation
Static Pressure Stability
± 0.5 hPa
Maximum Delivered Gas Temperature
≤ 43°C
Pressure
G2S B25VT: 4 to 25 hPa
G2S B30VT: 4 to 30 hPa
SpO₂
0% to 100%
Pulse Rate
40 to 240 BPM
Packing:
Dimension: 274 mm × 184 mm × 115 mm
Weight: 1.9 kg
