Throughput 60 tests/hour
Diff Type 3 Part
Parameters 21 Parameters
Operation Mode Fully Automatic
Printer Type External Only
LIS Connectivity USB
Sample Loading Open + Closed
Technical Specifications
Principle
Measurement Method:
Electric Impedance Method
Colorimetry Method
Parameters
Total Parameters: 21 Reportable Parameters
WBC, LYM%, MID%, GRAN%, LYM#, MID#, GRAN#
RBC, HGB, HCT, MCV, MCH, MCHC, RDW-CV, RDW-SD
PLT, MPV, PDW, PCT, P-LCR
Histograms: 3 (WBC, RBC, PLT)
Throughput
Sample Throughput: 60 samples per hour
Sample Mode
Whole Blood
Pre-diluted Blood
Sample Volume
≤ 20 μL
Memory & Storage
Data Storage: Up to 1,00,000 results
Includes histograms, scattergrams & patient information
Display
Screen Size: 10.4 inch Touch Screen
Display Type: LCD
Resolution: 800 × 600
Viewing Angle: 10° inclined for visual comfort
Quality Control
3-Level QC (L-J Graph, X-B)
Reagents
LH Lyse
One Diluent
Probe Cleaner (for maintenance)
Flag System
RBC, WBC, PLT abnormal sample flags
Supports customized test groups
Connectivity
4 × USB Ports
1 × LAN Port
HL7 Protocol supported
Compatible with LIS system
PERFORMANCE DATA
WBC: Precision ≤2.0% (3.5–15.0 ×10⁹/L), Linear Range 0–100 ×10⁹/L, Contamination Rate ≤0.5%
RBC: Precision ≤1.5% (3.0–6.0 ×10¹²/L), Linear Range 0–10 ×10¹²/L, Contamination Rate ≤0.5%
HGB: Precision ≤1.5% (100–180 g/L), Linear Range 0–250 g/L, Contamination Rate ≤0.6%
MCV: Precision ≤1.0% (70–120 fL)
PLT: Precision ≤4.0% (150–500 ×10⁹/L), Linear Range 0–1000 ×10⁹/L, Contamination Rate ≤1.0%
Dimensions (Approx.)
Width: 390 mm
Depth: 285 mm
Height: 390 mm
Weight
Net Weight: 16 kg
