Chamber Volume 100 L
Mount Type Vertical
Chamber Material Stainless Steel
Max Temperature 121°C to 134°C
Key Features
Hi-pressure triple wall (Double Chamber) vertical autoclave
Inner chamber made of SS 304 Stainless Steel
Middle water jacket & outer body fully Stainless Steel
Heavy duty radial locking system with wing nuts
Stainless Steel lid & locking ring
Front mounted W-type control panel
Digital temperature controller with indicator lights
Equipped with pressure gauge (0–30 PSI)
Double safety valve system
Steam release valve & vacuum release valve
Leak-proof and corrosion resistant construction
Inner removable container
Heavy tripod stand inside chamber
Heat resistant rubber gasket for airtight sealing
Mounted on sturdy Mild Steel / Stainless Steel legs
Suitable for hospitals, CSSD, pharma labs & research institutes
Working pressure range: 15–20 PSI
Technical Specifications
Type: Hi-Pressure Triple Wall Vertical Autoclave (W Type)
Chamber Size: 16 inch (Diameter) × 36 inch (Height)
Capacity: 100 Liters
Construction: Triple Wall (Inner Chamber + Water Jacket + Outer Body)
Material: Complete Stainless Steel construction
Working Pressure: 15–20 PSI
Maximum Pressure: 20 PSI
Operating Temperature: 121°C to 134°C
Pressure Gauge Range: 0–30 PSI
Heating System: Heavy duty immersion heaters in water jacket
Control System: Front mounted W-type digital control panel
Power Supply: 220–240V AC, 50 Hz, Single Phase
Safety System: Double safety valve + Steam exhaust valve
Sealing: Heat resistant rubber gasket
