Condition Refurbished A
Application ICU
Feature
Apnea Back-up Ventilation
Pressure Control and Pressure Support Variable Rise Time
Pressure Control and Pressure Support Variable Flow Termination
Leak Compensation
Technical Specification
Controls
Power: On / Standby
Ventilation Modes: Control, Assist/Control, SIMV, CPAP, NPPV
Breath Types: Volume Control, Pressure Control, Pressure Support, Spontaneous
Breath Rate: 0 – 80 breaths per minute
Tidal Volume: 50 – 2000 ml
Inspiratory Time: 0.3 – 9.9 seconds (100 lpm)
PC/PS/Spontaneous Flow: 160 lpm
Pressure Control: Off, 1 – 99 cmH₂O
Pressure Support: Off, 1 – 60 cmH₂O
Sensitivity: 0.1 lpm (inhalation)
PEEP/CPAP: 0 – 20 cmH₂O
Control Breath: Easy or Hard unlock methods 1 x current settings
Variable Alarms
Apnea Interval: 10 – 60 seconds
High Pressure Limit: 5 – 100 cmH₂O
Low Peak Pressure: Off, 1 – 60 cmH₂O
Low Minute Volume: Off, 0 – 99 liters
Alarm Volume: 60 – 85 dBA at 1 meter
Alarm Silence/Reset: 60 seconds
Ventilator Inoperative: Red LED, audible alarm
High Rate Alarm: Off, 5 – 80 bpm
High PEEP Alarm: Off, 3 – 40 cmH₂O
Fixed Alarms
Monitors and Indicators
Power Specifications : 11 – 15 VDC, 90 – 250 VAC, 47 – 63 Hz
Pneumatic Specifications: Low Pressure O₂ Source: <80 lpm, <10 PSIG
Environmental Specifications
Dimension : 81 x 23 x 30 cm
Weight : 6.1 kg
Disconnect/Sense Line
Low & Lost External Power
Low & Empty Internal Battery
High & Low Oxygen Inlet Pressure
Peak Inspiratory Pressure: 0 – 120 cmH₂O
Mean Airway Pressure: 0 – 99 cmH₂O
PEEP: 0 – 99 cmH₂O
Total Breath Rate: 0 – 250 bpm
Airway Pressure Display: -10 – 108 cmH₂O
Exhaled Tidal Volume: 0 – 4000 ml
Total Minute Volume: 0 – 99.9 liters
I:E Ratio: 99:1 – 1:99
Calculated Peak Flow: 10 – 100 lpm
Patient Effort: Green LED
Operating Temperature: 5° – 40°C (40° – 104°F)
Storage Temperature: -20° – 60°C (-4° – 140°F)
Operating Humidity: 15 – 95% relative
Storage Humidity: 10 – 95% relative
Shock Compliance: MIL-STD-810E
Vibration Compliance: MIL-STD-810E
