Chamber Volume 40 L
Mount Type Vertical
Chamber Material Stainless Steel 304
Max Temperature 121°C to 134°C
Heating Mode Electric
Key Features
Vertical heavy duty double wall construction
Inner chamber made of Stainless Steel (SS 304)
Outer jacket made of Stainless Steel
Double wall design for better heat insulation & safety
Radial locking system with heavy lid
Aluminium die-cast / Stainless Steel lid
Pressure gauge (0–30 PSI)
Double safety valve system
Steam release valve & vacuum release valve
Water level indicator (for jacket water level)
Rubber gasket for airtight sealing
Leak-proof and durable construction
Technical Specifications
Chamber Size: 12 inch (Diameter) × 22 inch (Height)
Capacity: 40 Liters
Construction: Double Wall (Inner Chamber + Outer Jacket)
Inner Chamber Material: SS 304
Outer Body: Stainless Steel
Working Pressure: 15–20 PSI
Maximum Pressure: 20 PSI
Operating Temperature: 121°C to 134°C
Heating: Electric immersion heaters placed in outer jacket
Power Supply: 220–240V AC, 50 Hz, Single Phase
Pressure Gauge Range: 0–30 PSI
Safety: Double safety valve + Steam release valve
Insulation: Water jacket insulation for uniform heating
