Display type LCD color
FHR channels normal FHR
Paper width 104mm
Connectivity WiFi
Mount type Wall mount
Printer type Built in
Performance
Safety
Type of protection against electric shock: Class I
Degree of protection against electric shock: Type B applied part
Working Voltage: AC 100 V~240 V
Frequency: 50 Hz/60 Hz
P < 60 VA
Fuse: T1.6AL250V
Print
Record paper: Z-fold paper
Print width: 112 mm
Valid print width: 104 mm
Paper speed: 1 cm/min, 2 cm/min, 3 cm/min (optional)
Network interface: RJ 45
Ultrasound probe
Nominal Frequency: 1.0 MHz
Work Frequency: 1.0 MHz ± 10%
Negative peak sound pressure: p₋ < 1 MPa
Output beam intensity: Iₛₒ < 20 mW/cm²
The peak time space peak intensity: Iₛₚ < 100 mW/cm²
The average time space peak intensity: Iₛₐₜₐ < 10 mW/cm²
FHR
Range: 50 BPM ~ 240 BPM
Resolution: 1 BPM
Accuracy: ± 2 BPM
TOCO
Range: 0 ~ 100%
Resolution: 1%
Nonlinear error: ≤ ± 10%
RZ way: manual
Fetal Marking
Manual button
Feature
Compact design; it can be placed horizontally or hung on the wall.
Color LCD, 60° convertible screen.
Displays monitoring curves and data clearly.
Area mark for normal FHR (120 BPM–160 BPM).
Manual record for fetal movement.
Sound and color reminders for high and low fetal heart rate.
Real-time monitoring for continuous 24 hours.
Storage, playback, and printing of monitoring curves for continuous 12 hours.
Optional interface languages: Chinese and English.
Optional twins monitoring.
9-crystal and broadband beam transducer.
Extra long-life, high-resolution built-in thermal printer.
Communication with central monitoring system via built-in RJ45.
Packing:
Dimension: 320 mm (L) x 260 mm (W) x 80 mm(H)
Weight: 3 Kg
