Channel Type Single Channel
Accuracy +-3 %
Occlusion Level High
Display Type LED
Power Source Rechargeable Battery
Feature
Injection rate and total volume can be set by users.
High priority alarms: occlusion, syringe out, motor abnormality, no syringe installed, battery exhaustion, enter KVO, pressure failure, etc.
General alarms: near completion, low battery, and standby prompt.
With bolus injection function, convenient for supplying temporary and rapid medication.
Automatically enters KVO mode after the injection is completed.
Built-in rechargeable battery automatically switches to battery power when mains power is interrupted and automatically charges when power is restored.
2.8″ LCD display.
Audible, visible, and text alarm prompt functions.
System parameters and syringe type settings are password protected to prevent unauthorized changes.
Disposable syringes meeting national standards can be used, and accuracy can be ensured by adjusting parameters.
Packaging
Dimension: 305(L) * 132(W) * 114(H) mm
Weight: 1.7 Kg
Performance
Syringe Specification:
10 ml / 20 ml / 30 ml / 50 ml syringes meeting national standards
Injection Rate:
10 ml syringe: 0.1 ml/h – 200 ml/h
20 ml syringe: 0.1 ml/h – 400 ml/h
30 ml syringe: 0.1 ml/h – 600 ml/h
50 ml syringe: 0.1 ml/h – 1200 ml/h
Bolus Rate:
10 ml syringe: 200 ml/h
20 ml syringe: 400 ml/h
30 ml syringe: 600 ml/h
50 ml syringe: 1200 ml/h
Accumulated Volume: 0 ml – 9999 ml
Injection Accuracy: ±3%
Occlusion Alarm Pressure Range:
Low: 40 kPa (±16 kPa)
Medium: 70 kPa (±30 kPa)
High: 100 kPa (±35 kPa)
KVO Rate: 0.1 ml/h
Classification:
Class II, Type BF applied part, internally powered equipment
Alarm Functions:
Occlusion, syringe out, motor abnormality, pressure failure, enter KVO, battery exhaustion, no syringe installed, near completion, low battery, standby prompt
